The Search for Efficiency

Announcements

• I actually got you Exam 2 results! gasp More on those in just a second
• Be working on the Infinite Adventure Project!
  • You have everything you need to complete it at this point
• Final
  • I will be posting final study materials and an old test a week from tomorrow so that you can start studying
  • Will be more weighted toward content from the latter half of the semester, but everything we’ve been doing this semester builds on earlier material
  • Adventure largely marks the end of testable material, though content we cover between now and the final may show up in some extra credit contexts
• I will be giving you time on the last day of class to complete our course course evals (the SAIs)

Midterm 2 Debrief

Exam Corrections

Helping Fellow Students

Review Activity!

• Last class we introduced the requests library, and you had a chance to use it in section this week
  • Didn’t get it installed? Downloading and running this may be easiest if pip doesn’t like you…
• Your attendance for today is to send a very simple payload with only a “name” key (and your name as the corresponding value) to the URL below:
  • URL:
• Should get a 201 status code in return if your name has been recorded in today’s attendance!
  • If you get something else, try again!
• Ask me if you are struggling!

Searching for Efficiency

A Linear Search

• Suppose you needed to determine if a particular element was in a list, and didn’t have any of the built-in methods available to you

• The easiest method (which many of you have indeed used!) is to just search through the list element by element and check it to see if it is the one you desire

  • This approach is called a linear search

• Easy to understand and implement:

  def linear_search(target, array):
      for i in range(len(array)):
          if array[i] == target:
              return i
      return -1

Searching for Area Codes

• To illustrate the efficiency of linear search, it can be helpful to work with a larger dataset
• We’ll look here at searching through potential US area codes to find that of Salem: 503
• Linear search examines each value in order to find the matching value.
  • As the arrays get larger, the number of steps required also grows
• As you watch linear search do its thing on the next slide, see if you can beat the computer at finding 503.
  • What approach did you take?

Linear Search in Action

How did you do?

• Frequently, many people can “beat the animation” in finding 503
• Approaches vary, but you may well have done something along the lines of:
  • Look at some number in the middle
  • Depending on how close it was to 503, jump ahead some in that direction and check again
• Requires some special conditions though, so let’s try again

Racing Linear Search Again

Idea of a Binary Search

• If your data is ordered, then you might try a alternative search strategy
• Look at the center element in the array, it is either:
  • The value you want. Excellent! Return it.
  • A value larger than what you want. Throw away that value and everything bigger.
  • A value smaller than what you want. Throw away that value and everything smaller.
• Then you can repeat the process with the remaining elements until you find your value
• Since number of searched elements is divided by 2 each time, this method is called a binary search

Binary Search in Action

Implementing Binary Search

def binary_search(target, array):
    lh = 0
    rh = len(array) - 1
    while lh <= rh:
        middle = (lh + rh) // 2
        if array[middle] == target:
            return middle
        elif array[middle] < target:
            lh = middle + 1
        else:
            rh = middle - 1
    return -1

Linear Search Efficiency

• The running time of the linear search depends on the size of the array
  • That in itself is not particularly surprising. The running time of most algorithms will depend on the size of the problem to which the algorithm is applied.
• For many applications, it is easy to come up with a numeric value that describes the problem size, commonly called \(N\).
  • For most lists, \(N\) is simply the length of the array
• In the worst case, when the target value is the last element of the list or does not appear at all, the linear search requires \(N\) steps
  • On average, it takes about half that, or \(\frac{N}{2}\)
  • Computer scientists are pessimists though, and will generally use the worse case scenario to compare

Binary Search Efficiency

• The running time of binary search also depends on the size of the array, but in a very different way
• Each step of the process, the binary search rules out half the remaining options
  • The worst case (which we had earlier!) requires a number of steps equal to however many times we can divide the array in half until we have only a single number left.
  • Mathematically, this looks like \[1 = N / \underbrace{2 / 2 / 2 / 2 \cdots / 2}_{k\text{ times}} = \frac{N}{2^k}\]
• We really want to know the number of steps, \(k\), so solving for \(k\): \[2^k = N \quad\Rightarrow\quad k = \log_2(N)\]

Comparing Efficiencies

• The below table illustrates the differences in the number of required steps for the two search algorithms

• Clearly, for large values, the difference in the number of steps is enormous
• At 1 million elements, the binary search is 50,000 times faster!

Sorting

• Binary search only works on arrays in which the elements are ordered.
  • The process of putting the elements into order is called sorting.
• Lots of different sorting algorithms, which can vary substantially in their efficiency.
• From an algorithms view, sorting is probably the most applicable algorithm we’ll discuss in this course
  • Organizing data makes it easier to digest that data, whether the data is being digested by other machines or by humans
